High test chain G43 ASTM80 Standard Link Chain
Product Description:

Material: Carbon Steel

Surface: Bright finishing, electric galvanized and hot dip galvanized.

Packing: Gunny bag, plastic drum, iron drum, plastic reel, pallet

Specifications:

The available Grades of our chains are G-28, G-43, G70 and G80. Custom chains also can be made according to supplied drawings.
Our company manufactures chains ranging from Dia. 2mm to 34mm, including
Carbon steel link chain,
Tire chain,
Stainless steel link chain
Chain assemblies,
Covering over 300 different sizes and types.

Item No.	Trade size	Material Diameter		Working Load Limit		Proof test		Breaking Force Minimum		Max Length Per 100 Links		Max weight per 100 feet
Item No.	Trade size	in	mm	lbs	kg	lbs	kn	lbs	kn	in	m	lbs	kg
ZHLC-AH-1/4	1/4	0.281	7.1	2600	1180	4300	19.1	7750	34.5	98	2.49	84	38
ZHLC-AH-5/16	5/16	0.434	8.7	3900	1770	6400	28.5	11600	51.6	110	2.79	120	54
ZHLC-AH-3/8	3/8	0.406	10.3	5400	2450	8900	39.6	16200	72.1	134	3.4	176	80
ZHLC-AH-7/16	7/16	0.468	11.9	7200	3260	11900	52.9	21500	95.6	140	3.55	230	104
ZHLC-AH-1/2	1/2	0.531	13.5	9200	4170	15300	68.1	27600	122.8	150	4.06	300	136

All our activities are accredited to ISO 9001 and based on delivering the highest quality possible, both in products and services, ensuring longterm benefits and optimum performance.

Also we got the below certification: CE GS SUV, LR ABS ( anchors and anchor chains) Our rigging hardware is manufactured under exceptional quantity control and strictly adhered to the US, DIN, JIS, BS and AS standards.
