Stainless Steel Leaf Chains

Product Description

Our Stainless Steel Leaf Chains meet DIN, ANSI, ISO, BS, JS standard, and our chains stand up to the toughest working environments
Leaf Chains - Lifting and Pulling Chains - Haulage Chains
AL Series Light Duty Leaf Chains: AL422 - AL1666
BL (LH) Series Heavy Duty Leaf Chains: BL422 - BL2088
BL (LH) Corrosion Resistant Leaf Chains: BL422DT - BL1088
LL Series Light Duty Leaf Chains (ISO 4347, DIN 8152): LL0822 - LL3266
Stainless Steel Leaf Chains (AL and Bl/LL series) on request.
Car Parking Chain: 80LT - 120LT
Galle Chain (DIN 8150): 1520 120180
Bar and Pin Chain (Stud Chain): BP2104 - BP2136
Draw Bench Chains (DIN 8156 & DIN 8157): DB and BD Series
Heavy Duty Straight Sidebar Chain: Z2814 - Z5628
Standard Bucket Elevator Chains: DT150 - DT250
Round Link Chains for Lifting Applications
Roller Chain and Bush Chain for Lifting Applications

Our leaf chain is widely used in industrial field such as fork liftor and so on
Our quality is reliable and meet ISO standard and exported in big quantity
There are grey colour, shot peened, blue, black, yellow colour chain plate available.
There are grease and anti-rust oil available for lubrication for chain
We can produce as per your drawing or sample and we can also help you to design the chain to meet your special request.

P	P	d1(max)	b1(min)	Pt	N	N	h2(max)	Q	Q	Q
in	mm	mm	mm	mm	N	N	mm	KN	KN	KN
60	3/4"	19.05	11.91	12.70	22.78	1099	1833	18.08	31.27	62.54	93.81
80	1"	25.40	15.87	15.88	29.29	1944	3238	24.13	55.60	111.20	166.80
100	11/4"	31.75	19.05	19.05	35.76	2825	4715	30.18	86.84	173.68	260.52
120	11/2"	38.10	22.22	25.40	45.44	3821	6361	36.20	125.10	250.20	375.30
140	13/4"	44.45	25.4	25.40	48.87	4982	8363	42.24	170.27	340.54	510.81
160	2"	50.80	28.57	31.75	58.55	6316	10542	48.26	222.40	444.80	667.20
180	21/4"	57.15	35.71	35.71	65.84	9430	15747	54.31	281.57	563.14	844.71
200	21/2"	63.50	39.67	38.10	71.55	12188	20373	60.33	347.41	694.82	1024.23
240	3"	76.20	47.62	47.62	87.83	15747	23931	72.39	500.40	1000.80	1501.30
