Us Type Galv Malleable Wire Rope Clip
Our main produce include shackles, clips, turnbuckles, load binders, hooks, eye bolts and nuts, wire rope, chains, snap hooks, stainless steel and solid brass riggings etc.If you need this product&am......
Send Inquiry
Product Description
Our main produce include shackles, clips, turnbuckles, load binders, hooks, eye bolts and nuts, wire rope, chains, snap hooks, stainless steel and solid brass riggings etc.
If you need this product, let us know ASAP.
WE ARE WAITING FOR YOU!
SIZE 1/16'' to 1-1/8'' US Type Galv Malleable Wire rope Clips
Essential hardware item for rigging rope, wire and cable
Zinc-galvanized for superior rust & corrosion resistance
Easy to attach, remove & reuse with hand tools
Dual nuts squeeze clamp tight for firm hold; use for anchoring, making loops, adjusting length
drawing:
http://grandlifting.en.made-in-china.com
Our Service," Your Safety, Customers Satisfaction, Our Pursuit ". To provide the most suitable products and pragmatic services is our firm belief. We can design and manufacture varies of products according to customers requirements. We have been putting the priority to the QUALITY, SINCERITY, EFFICIENCY, and SERVICE.
Sincerely wish long-term cooperation between you and us. Warmly welcome to our company for a visit.
For More information, please visit our website: grandlifting.en.made-in-china.com
Our products include: lever block, push trolley & geared trolley, I beam clamp, lifting clamp, snatch block, webbing sling, endless type webbing sling, round sling, cloverleaf slings, slings bags, grade 80 chain and chain sling, chain fittings, ratchet tie down, ratchet straps, cargo lashing, ratchets, ratchet type load binder, lever load binder, hand winch, hand puller, winch strap, tow straps, logistic strap,winches, rigging hardware, marine hardware, anchors, anchor chains, turnbuckles, shackles, stainless steel rigging, etc.
Please do not hesitate to contact us, if there are any questions or enquiries.
If you need this product, let us know ASAP.
WE ARE WAITING FOR YOU!
SIZE 1/16'' to 1-1/8'' US Type Galv Malleable Wire rope Clips
Essential hardware item for rigging rope, wire and cable
Zinc-galvanized for superior rust & corrosion resistance
Easy to attach, remove & reuse with hand tools
Dual nuts squeeze clamp tight for firm hold; use for anchoring, making loops, adjusting length
drawing:
http://grandlifting.en.made-in-china.com
| ITEM NO | SIZE | G | E | A | L | C | D |
| in | in | in | in | in | in | in | |
| ZHWRC-DF-1 | 1/8 | 0.44 | 0.47 | 0.94 | 0.72 | 0.81 | 0.22 |
| ZHWRC-DF-2 | 3/16 | 0.56 | 0.59 | 1.16 | 0.97 | 0.94 | 0.25 |
| ZHWRC-DF-3 | 1/4 | 0.63 | 0.75 | 1.44 | 1.03 | 1.19 | 0.31 |
| ZHWRC-DF-4 | 5/16 | 0.75 | 0.88 | 1.69 | 1.38 | 1.31 | 0.38 |
| ZHWRC-DF-5 | 3/8 | 0.75 | 1 | 1.94 | 1.5 | 1.63 | 0.44 |
| ZHWRC-DF-6 | 7/16 | 1 | 1.19 | 2.28 | 1.88 | 1.81 | 0.5 |
| ZHWRC-DF-7 | 1/2 | 1 | 1.19 | 2.28 | 1.88 | 1.91 | 0.5 |
| ZHWRC-DF-8 | 9/16 | 1.25 | 1.31 | 2.5 | 2.25 | 2.06 | 0.56 |
| ZHWRC-DF-9 | 5/8 | 1.25 | 1.31 | 2.5 | 2.38 | 2.06 | 0.56 |
| ZHWRC-DF-10 | 3/4 | 1.44 | 1.5 | 2.84 | 2.75 | 2.25 | 0.62 |
| ZHWRC-DF-11 | 7/8 | 1.63 | 1.75 | 3.16 | 3.13 | 2.44 | 0.75 |
| ZHWRC-DF-12 | 1 | 1.81 | 1.88 | 3.47 | 3.5 | 2.63 | 0.75 |
| ZHWRC-DF-13 | 1-1/8 | 2 | 2 | 3.59 | 3.88 | 2.81 | 0.75 |
| ZHWRC-DF-14 | 1-1/4 | 2.13 | 2.31 | 4.13 | 4.25 | 3.13 | 0.88 |
| ZHWRC-DF-15 | 1-3/8 | 2.31 | 2.38 | 4.19 | 4.63 | 3.13 | 0.88 |
| ZHWRC-DF-16 | 1-1/2 | 2.38 | 2.59 | 4.44 | 4.94 | 3.41 | 0.88 |
| ZHWRC-DF-17 | 1-5/8 | 2.63 | 2.75 | 4.75 | 5.31 | 3.63 | 1 |
| ZHWRC-DF-18 | 1-3/4 | 2.75 | 3.06 | 5.28 | 5.75 | 3.81 | 1.13 |
| ZHWRC-DF-19 | 2 | 3 | 3.38 | 5.88 | 6.44 | 4.44 | 1.25 |
| ZHWRC-DF-20 | 2-1/4 | 3.19 | 3.38 | 6.38 | 7.13 | 4.56 | 1.25 |
